Hyper USB-C HyperDrive GEN2 Thunderbolt 3 docking station

The HyperDrive GEN2 14 Port Thunderbolt™ 3 Dock is a powerful, enterprise-level Dock featuring 14 ports and boasts 2X faster refresh rate, 2X faster data transfer speeds and 2X faster power delivery charging. One TB3 downstream port provides 40Gbps data transfer and 15W of power for any TB3 peripherals while the one TB3 upstream port supplies 85W power delivery to the host computer.

It allows dual 4K 60Hz display support as well as the choice between 8K 30Hz or 4K 120Hz single display support. Also, enjoy Gigabit Ethernet, Digital Coaxial and Optical Toslink audio. Additionally, you can daisy chain six TB3 Docks or devices to HyperDrive. Includes a 180W power adapter.

1 x TB3 Upstream Port
The powerful Thunderbolt 3 upstream port provides 40Gbps data transfer speed and 85W Power Delivery to the host computer.

1 x TB3 Downstream Port
The powerful Thunderbolt 3 downstream port provides 40Gbps data transfer, 15W of power for any peripherals, and DP 1.4 video.

Daisy Chain Six TB3 Devices
Maximize your workflow by daisy chaining up to 6 x Thunderbolt 3 docks or devices to HyperDrive.

Dual 4K 60Hz Display Support
HyperDrive supports dual 4K 60Hz display support through TB3 and DP 1.4 connection.

Single 8K 30Hz or 4K 120Hz Display Support
HyperDrive also gives you the choice of 8K 30Hz or 4K 120Hz single display support through TB3 or DP 1.4 connection.

Fast & Reliable Gigabit Ethernet
Get the most reliable and fastest internet connection for work, play, and video conferencing.

High-Speed USB
Blazing-fast 2nd generation USB-A 3.2 10Gbps and USB-C 3.2 10Gbps with 2X faster transfer speed than our 1st generation hubs.

Pro-Grade Digital Audio
Capture and listen to the best sound quality possible with digital coaxial audio, optical Toslink audio, and a 3.5 mm Audio Combo Jack.

Features
• Host: Thunderbolt 3 Upstream (40Gbps; 85W PD)
• Thunderbolt 3 Downstream (40Gbps; 15W)
• DisplayPort 1.4 (8K 30Hz; 4K 120Hz; HDR)
• USB-C (10Gbps)
• USB-A (10Gbps)
• USB-A (10Gbps)
• USB-A (5Gbps)
• USB-A (5Gbps)
• USB-A (5Gbps)
• USB-A (24W QC 3.0)
• 1 Gigabit Ethernet
• 3.5mm Audio Combo Jack
• Digital Coaxial
• Optical Toslink

Physical Characteristics:
• Dimensions: 130.18 x 88.9 x 44.45 mm
• Weight: 589.7 g

Connectivity
• Host: Thunderbolt 3 Upstream (40Gbps; 85W PD)
• Thunderbolt 3 Downstream (40Gbps; 15W)
• DisplayPort 1.4 (8K 30Hz; 4K 120Hz; HDR)
• USB-C (10Gbps)
• USB-A (10Gbps)
• USB-A (10Gbps)
• USB-A (5Gbps)
• USB-A (5Gbps)
• USB-A (5Gbps)
• USB-A (24W QC 3.0)
• 1 Gigabit Ethernet
• 3.5mm Audio Combo Jack
• Digital Coaxial
• Optical Toslink

Power
• Host: Thunderbolt 3 Upstream (40Gbps; 85W PD)
• USB-A (24W QC 3.0)

Compatibility:
• macOS 10.16 or Later: Yes
• Windows 7 or later: Yes
• Chrome OS (latest): Yes
• Linux: Yes
• iPad OS: Yes
• Android: No

Compatible Devices:
• MacBook Pro 2016 or Later
• MacBook Air 2018 or Later
• MacBook 2015, 2016
• iPad Pro 2018 or later
• iPad Air 2020 or later
• Windows OS laptop with Thunderbolt 3/4, USB4, USB 3.0 or later Type C with DP Alt-Mode
• Chrome OS laptop with Thunderbolt 3/4, USB4, USB 3.0 or later Type C with DP Alt-Mode
• Any other device with USB-C

Monitor Support Capability:
• Single Monitor (Max output): 8K 30Hz / 4K 120Hz
• Dual Monitor (Max output): 4K 60Hz

Certifications:
• CE, UKCA, FCC, RCM, ICES003, PAHs, RoHS, REACH, WEEE, SOR, Prop65, TSCA

Requirements:
• M1 MacBook (2020 MacBook 13” Air & 2020 MacBook 13” Pro) will not support multi-display connectivity, but will be compatible with the rest of the dock’s ports.
• USB-A ports will not support Apple SuperDrive or charge iPads.
• The host device’s USB-C port must support Power Delivery, DisplayPort Alt Mode, and Thunderbolt 3.
